Features:
By using the high performance sensor, image is clear, delicate and high performance sensor, image is clear, delicate;
Analog HD AHD-H@AHD video output;
The transmission distance is 500 meters;
Support automatic electronic shutter function, adapt to different monitoring environment;
Million pixel HD video transmission of low cost, long distance, no delay, high efficiency, anti-jamming and easy to implement;
Easy installation & operation, as same as analog CCTV system
More acceptable, lower price than analog surveilance system
NO Delay, Real time Display
Installation Notes:
(1) Do not use this product falls on the ground or by strong percussion;
(2) unless instructed otherwise, do not dismantle the machine;
(3) before use to determine whether the specified power supply voltage;
(4) to avoid targeting light (such as sunlight, lighting, etc.), otherwise easily lead to too bright or pull light phenomena (this is not a failure), will also affect the CCD life;
(5) Avoid wet conditions, dust, extreme heat, extreme cold, strong electromagnetic radiation and other venues;
(Not include OSD Menu and Power Supply ,Suggest Camera Don't use completely dark environment)
important Notes:
1>>This is Full HD AHD 1920P Camera ,Work Must use 1080P Recording Format AHD DVR (AHD-H System or AHDN-1080N System)!! If NO USE 1080P Record AHD DVR, AHD Camera NOT Work .
2>>You Can't use AHD-M SYSTEM 720P Record AHD DVR and Common DVR ,the AHD Camera it NOT Work!!!
3>>Camera Work Can only use 1080P Record AHD DVR!!!
Specification
Main Chip
High performance
Sony processor
Image Sensor
1080P:1/3 Sony IMX323+NVP2441H
3MP:1/3 Sony IMX291+FH8536E ( Starlight )
Effective Pixel
PAL : 1920*1080@25fps
NTSC : 1920*1080@30fps
Signal System PAL/NTSC
Video Standard Follow AHD and CVBS Standard
Video Output 1CH AHD HD/CVBS Standard Singal Output(Switchable)
Max Transmission Distance Common 75-3 Cable can be up to 500m
HD 3MP Lens size 3.6MM
Minimum Illumination 0.0001LUX/F1.2(Led on)
3D Noise Reduction YES
LED NO
Lightning protection YES
Shutter Speed 4/25s-1/45,000s
BLC Off/Low/Medium/High/Highest
White Balance Auto White Balance
HLC Auto
Operation Temperature -45°C~55°C
Power Supply DC12V
Housing Material Metal
IP Grade IP65 indoor
